TA1107H25S X 1-11/16 STR BR REDR
901146 - TA1107H25S X 1-11/16 STR BR REDR - TA II Reducer
| General | |
|---|---|
| REDUCTION TYPE | Double Stage |
| GEARBOX COMPONENT TYPE | Gearbox |
| CASE SIZE | 1 |
| OUTPUT STYLE | Straight Bore |
| HOUSING MATERIAL | Cast Iron |
| Sealing & Lubrication |
|
|---|---|
| SEAL TYPE | Two-Piece |
| Technical |
|
|---|---|
| MAXIMUM SPEED INPUT | 2005 rpm |
| INPUT STYLE | Belt-Driven |
| Dimensions |
|
|---|---|
| BORE LENGTH OUTPUT | 5.8200 in |
| DEPTH | 10.0000 in |
| SHAFT DIAMETER INPUT | 1.0000 in |
| SHEAVE DIAMETER MINIMUM | 5.4000 in |
| Miscellaneous |
|
|---|---|
| AGMA SIZE | 107 |
| ACTUAL RATIO | 25.0600 |
